Description
Type Single display
Display method 4-digit 7-segment LED
Light source Red LED(660nm)
Response time 150℃, 500?, 4ms
Power supply 12-24VDC ⎓ ±10%(ripple P-P: max. 10%)
Current consumption Max. 50mA
Operation mode Light ON/Dark ON(set by parameter)
Control output NPN open collector
Timer function OFF, OFF Delay(10ms, 40ms)
Sensitivity adjustment Manual Teaching(auto-tuning, 1-point, 2-point, positioning)
• In multiple connection, batch teaching available
Communication I2C(max. 8 units)
Environment_Ambient illumination Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination)
Environment_Ambient temperature -10 to 50℃, storage: -20 to 70℃
Protection structure IP40
Approval
Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH
Mutual interference prevention Max. 8 unit sets(automatically set regardless of response time)
Material Case: Polybutylene terephthalate, Cover: Polycarbonate
Accessories Connector type wire(Ø4mm, 3-wire, 2m)(AWG22, core diameter: 0.08mm, number of cores: 60, insulator out diameter: Ø1.25mm), Side connector
Weight Approx. 138g(approx. 20g)
